Borehole Exploration Water Well Drilling Rig for Tough Environment Condition

Name: Borehole Exploration Water Well Drilling Rig for Tough Environment Condition
Brand: JINZHOU SHITAN
Price: 1 USD

Wholesale Borehole Exploration Water Well Drilling Rig for Tough Environment Condition from china suppliers

Brand Name : JINZHOU SHITAN

Model Number : ST-300

Certification : ISO,CE,SGS,TUV,BV

Place of Origin : China

MOQ : 1 set

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 2000 sets per year

Delivery Time : 7-10 days

Packaging Details : 1, plastic bags inside,wooden boxes outside,or as customers'request 2, seaworthy packing

Place Of Origin : China (Mainland)

Model Numbe(m) : ST-200

Open Hole Caliber : 75

Warranty : 1 year

Contact Now

Borehole Exploration Water Well Drilling Rig for Tough Environment Condition

Product Descrption:

Jinzhou Shitan top hammer drill rigs are equipped with powerful hydraulic rock drills that offer high penetration rates, reliability, and excellent fuel economy. These diesel-powered rigs represent the industry's leading range, from lightweight rubber-tire drills to the most powerful production drills available.

Jinzhou Shitan surface top hammer drill rigs are renowned for their exceptional reliability even in the toughest conditions. Between their excellent fuel economy and low operating costs, these diesel-powered, self-propelled drill rigs are designed for both enterprise/industry usage & personal family usage.

Main Parameter:

(1) Rated drilling depth:200m,The deepest shall not exceed 220m.

Rated opening diameter:200mm.

Maximum opening diameter : 300mm.

Drilling depth and drilling diameter shall be determined according to the formation conditions.
(2) The vertical speed (four steps):118,236,505,1010.r/rain
(3) Max output torque:1500N. m
(4) Maximum weight (a speed of single rope):17KN
(5) drill pipe diameter:42mm
(6) Borehole inclination:90~75°
(7) Rig overall dimensions·(L×B×H)1433×697×1273mm
(8) Rig weight:500kg(Transfer machines 620kg, transfer machine with pump 720kg)

Borehole Exploration Water Well Drilling Rig for Tough Environment Condition

Product Tags:

water borehole drilling equipment

hydraulic water well drilling machine

Borehole Exploration Water Well Drilling Rig for Tough Environment Condition Images
